Gargo Sample Dyeing Machine

We are engaged in manufacturing & supplying of HTHP Automatic Yarn Cone Sample Dyeing Machines Ranging from 250gms to 5kg. It is used for dyeing yarn at high temperature and high pressure. Our expert technicians ensure that it is manufactured using fine grade material, procured from the most authentic vendors of the industry. The body of the machine is fabricated using high grade stainless steel in order to assure durability and resistance to corrosion. We fabricate these machines using premium quality raw material that is procured from the most credible vendors of the industry. We have all the requisite facilities to manufacture and offer a technologically advanced range of Sample Dyeing Machine / Single Package / Pilot Yarn Dyeing Machine. Manufactured using quality materials, these are appropriate for dyeing of loose fibers, tops, tows, yarn packages and yarn beams with suitable material carriers.

Sample Dyeing Machine
Sample Dyeing Machine

Main Features:

  • Capacity from 250gms to 5kg
  • Micro-controller temp. programmer with reverse-forward timer
  • Bi-Directional main pump (Direct drive -motor mounted)
  • Variable Frequency Inverter Drive For main pump
  • Steam heat exchanger for efficient and fast heat transfer
  • Electric heater for heating without steam
  • Design ensures complete drain of liquor
  • SS spring safety valve
  • Electronic pressure switch for over pressure release.
  • Pump dry run sensor.
  • High temp. Drain.
  • Differential Pressure Guage
  • Wo. temp up to 1400C
  • Wo. Pr. Up to 4 kg/cm2 (vessel tested pressure 7 kg/cm2)
